Deck Oven

A reliable deck oven that works for both confectionery and bakeries. The D-Series consists of robust, reliable and energy-efficient ovens with double temperature sensors to ensure an even heat distribution throughout the oven interior, which gives excellent baking results.

Description

A reliable deck oven that works for both confectionery and bakeries.

The D-Series consists of robust, reliable and energy-efficient ovens with double temperature sensors to ensure an even heat distribution throughout the oven interior, which gives excellent baking results. The model selection is broad, which makes the series suitable for different types and sizes of bakery. The deck oven is also modular, allowing the possible addition of up to five decks.

The deck oven is available in five different widths and is heated by electricity. It is well insulated, which leads to a good working environment while also using less energy. The heating elements are placed inside the all-welded oven and regulate the top, bottom and front heating evenly. The oven is also equipped with a power guard that monitors and controls the power output. The deck oven is equipped with radiation cover and turbo function, which means that it quickly reaches the desired baking temperature.

The few moving parts of the oven along with its robust handle and seals that can withstand high temperatures makes it easy to clean and maintain. The sections come apart for easier assembly in small spaces. Equipped with a stone sole and steam, this is an incredibly flexible oven that offers endless possibilities in professional baking of sourdough bread, bread and more delicate baked goods for a reasonable price.

● Robust construction

● Bottom hinged doors for easy loading

● Top and bottom elements individually controlled for each deck

● Individually controlled internal lighting per deck

● Fitted with glass viewing windows

● Timer with buzzer individually controlled per deck

● Fitted with (4x) castors for easy cleaning

Specifications

Specification

Dimension

Voltage

Power source

Power

Temperature

Suitable pan size

1 deck 2 trays

1330*890*650mm

220V,50HZ

Gas

0.1KW

20-400°C

400*600mm

2 deck 4 trays

1330*890*1420mm

220V,50HZ

Gas

0.2KW

20-400°C

400*600mm

3 deck 6 trays

1330*890*1705mm

220V,50HZ

Gas

0.3KW

20-400°C

400*600mm

3 deck 9 trays

1770*890*1705mm

220V,50HZ

Gas

0.3KW

20-400°C

400*600mm

3 deck 12 trays

1770*1160*1705mm

220V,50HZ

Gas

0.3KW

20-400°C

400*600mm

4 deck 16 trays

1770*1160*2155mm

220V,50HZ

Gas

0.4KW

20-400°C

400*600mm

1 deck 2 trays

1220*820*575mm

380V,50HZ

Electric

6.6KW

20-400°C

400*600mm

2 deck 4 trays

1220*820*1310mm

380V,50HZ

Electric

13.2KW

20-400°C

400*600mm

3 deck 6 trays

1220*820*1530mm

380V,50HZ

Electric

19.8KW

20-400°C

400*600mm

3 deck 9 trays

1660*820*1530mm

380V,50HZ

Electric

25.2KW

20-400°C

400*600mm

3 deck 12 trays

1660*1090*1530mm

380V,50HZ

Electric

25.2KW

20-400°C

400*600mm
